Specifications

• ENGINE

  add remove
  • Engine Type:
    Horizontal In-line
  • Cylinders:
    4
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    16
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (in):
    2.6
  • Stroke (in):
    1.77
  • Displacement (cc):
    600
  • Fuel Injector:
    Yes
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Horsepower (bhp):
    120
  • Compression ratio:
    12.4:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Overdrive:
    No
  • Primary Drive (Rear Wheel):
    Chain
  • Gear Ratio (1):
    2.85
  • Gear Ratio (2):
    1.56
  • Gear Ratio (3):
    1.56
  • Gear Ratio (4):
    1.33
  • Gear Ratio (5):
    1.19
  • Gear Ratio (6):
    1.08
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    79.7
  • Width (in):
    27.2
  • Height (in):
    42.9
  • Wheelbase (in):
    54.3
  • Ground Clearance (in):
    5.3
  • Dry Weight (lbs):
    357
  • Fuel Capacity (gal):
    4.5
  • Engine Displacement to Weight (cc):
    1.68
  • Turning Radius (ft):
    11.2
  • Wet Weight (lbs):
    401
  • Payload Capacity (lbs):
    426
  • Fuel Capacity Reserve (gal):
    0.92
• SUSPENSION

  add remove
  • Front Suspension Type:
    Telescopic Fork
  • Front Suspension Size (in):
    1.69
  • Front Travel (in):
    4.7
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    Yes
  • Front Central Suspension Strut:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    4.7
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Tube / Tubeless:
    Tubeless
  • Tires:
    Standard
  • Tire Brand:
    Dunlop®
  • Front Tire (Full Spec):
    Dunlop 120/60 ZR17
  • Front Wheel Width (in):
    3.5
• BRAKES

  add remove
  • Front Brake Type:
    Dual Disc
  • Front Brake Diameter (in):
    11.7
  • Rear Brake Type:
    Disc
  • Rear Brake Diameter (in):
    8.6
  • Regenerative Braking:
    Not Available
  • Regenerative Deceleration:
    Not Available
• SEATS

  add remove
  • Seat Type:
    Two-Piece
  • Seat Location:
    Driver and Passenger
  • Seat Material:
    Vinyl
  • Seat Specifications:
    Standard
  • Seat Height (in):
    32.3
  • Number Of Seats:
    2
  • Detachable Passenger Seat:
    Not Available
  • Seat Backrest:
    Not Available
  • Grab Rail or Strap:
    Standard
