Specifications

• ENGINE

  add remove
  • Engine Type:
    V Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Torque (Ft Lbs):
    119.6
  • Torque (Nm):
    162
  • Valves:
    4
  • Valve Configuration:
    OHV - Pushrod
  • Bore (in):
    4.06
  • Stroke (in):
    4.45
  • Displacement (cc):
    1890
  • Compression Ratio:
    11:0:1
  • Torque RPM:
    2900
  • Fuel Injector Size (mm):
    54
• TRANSMISSION

  add remove
  • Number Of Speeds:
    6
  • Gear Ratio (1):
    2.73
  • Gear Ratio (2):
    1.86
  • Gear Ratio (3):
    1.385
  • Gear Ratio (4):
    1.1
  • Gear Ratio (5):
    0.94
  • Gear Ratio (6):
    0.81
  • Final Drive Ratio:
    2.2
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    90.6
  • Width (in):
    30.5
  • Height (in):
    46.5
  • Wheelbase (in):
    64.6
  • Dry Weight (lbs):
    691
  • Wet Weight (lbs):
    714
  • GVWR (lbs):
    1160
  • Fuel Capacity (gal):
    4
  • Engine Displacement to Weight (cc):
    2.74
  • Ground Clearance (in):
    5
• WHEELS & TIRES

  add remove
  • Front Tire (Full Spec):
    Metzeler CRUISETEC™ 130/60 B19 (61H)
  • Rear Tire (Full Spec):
    Metzeler CRUISETEC™ 180/65 B16 (81H)
